Description
Magpul MBUS Gen 2 Flip-Up Rear Sight – Stealth Gray
The MBUS (Magpul® Back-Up Sight) is a low-cost, color injection molded, folding back-up sight. The dual aperture MBUS Rear Sight is adjustable for windage and fits most 1913 Picatinny rail equipped weapons, but is specifically tailored to the AR15 / M16 platform.
FEATURES :
- Impact resistant polymer construction provides light weight and resists operational abuse
- Spring-loaded flip up sight easily activated from either side or by pressing the top
- Detent and spring pressure keeps sight erect but allows for unobstructed folding under impact, etc.
- Clamps to most any MIL-STD-1913 Picatinny/STANAG 4694 rail and provides the same height-over-bore as standard A2 irons
- Protective wings shield the spring-locking A2 front sight post; Elevation adjustment tool included, but most aftermarket A2 front sight adjustment tools may be used as well
SPECIFICATIONS :
| Position | Rear |
| Height above rail, stowed | ~0.51 in. |
| Length, deployed | 1.5 in. |
| Length, stowed | 2.6 in. |
| Weight, w/ hardware | 1.3 oz. |
| Center of aperture to top of rail | 1.42 in. |
| Windage Adjustment | ~0.7 MOA (0.754″/100m) per click with a 14.5″ sight radius |
| ~0.5 MOA (0.547″/100m) per click with a 20″ sight radius | |
| Color | Stealth Gray |
| Item Weight | 1.3 oz. |
| Material | Polymer |
| Magnification Minimum | 1 x |
| Mounting Type | Picatinny Mount |
| Night vision | No |
| Brand | Magpul |
| Manufacturer Number | MAG248-GRY |
